About the company
TETA is a designer and manufacturer of electron beam machines, founded in 2008. We have our own research and manufacturing base, this enables us to carry out full range of design, technology and production tasks.
Company’s production facility includes:
TETA primarily focused on electron beam machines. We specialize in supplying the electron beam welding machines (standard and custom designed), and we install, commission and service them for our clients.
Our Company employs highly experienced personnel of 60 professionals with extensive expertise in development and fabrication of electron beam guns, vacuum systems, electric drives, and process control systems. Together our leading scientists and engineers have more than 20 years’ experience working as a team on collaborative scientific and engineering projects.
Our quality control system confirms to the ISO 9001:2008 standard. We successfully supply machinery to diverse industries, including aerospace, nuclear, metallurgy, instrument and automotive.
Company’s product range includes:
Beam power | 6 kW |
Welding chamber size | 500×500×500 mm |
Accelerating voltage | 60 kV |
Beam current MAX | 100 mA |
Beam current stability | 0.1 mA |
Beam deflection angle | ±7° |
Cathode | filament, indirect heater |
Operating vacuum | 5·10-2 Pa |
Ultimate vacuum | 5·10-3 Pa |
Pump time | 2 – 10 min |
Pump type | Turbomolecular and rotary vane |
Manipulator, axis number | 4 |
Coordinate table | 160×200 mm |
Х, Y, Z axis travel | 250, 250, 300 mm |
X, Y, Z axis movement speed | 0.1 – 40 mm/sec |
Table plate diameter | 160 mm |
Table plate aperture | 80 mm |
Rotation speed | 0.1 – 60 rpm |
Manipulator loading capacity | 50 kg |
Cooling system | Closed, integrated |
Pneumatic system | Integrated |
Supplies | Three-phase, 380V, 50 (60) Hz |
Weight | 1100 kg |
Beam power | 6 kW |
Welding chamber size | 800×800×800 mm |
Accelerating voltage | 60 kV |
Beam current MAX | 100 mA |
Beam current stability | 0.1 mA |
Beam deflection angle | ±7° |
Cathode | filament, indirect heater |
Operating vacuum | 5·10-2 Pa |
Ultimate vacuum | 5·10-3 Pa |
Pump time | 15 min |
Pump type | Turbomolecular and rotary vane |
Manipulator, axis number | 4 |
Coordinate table | 300×320 mm |
Х, Y, Z axis travel | 400, 400, 300 mm |
X, Y, Z axis movement speed | 0.1 – 40 mm/sec |
Table plate diameter | 300 mm |
Table plate aperture | 80 mm |
Rotation speed | 0.1 – 60 rpm |
Manipulator loading capacity | 70 kg |
Cooling system | Closed, integrated |
Pneumatic system | Integrated |
Supplies | Three-phase, 380V, 50 (60) Hz |
Weight | 1700 kg |
Beam power | 6 kW |
Welding chamber size | 800×800×1460 mm |
Accelerating voltage | 60 kV |
Beam current MAX | 100 mA |
Beam current stability | 0.1 mA |
Beam deflection angle | ±7° |
Cathode | filament, indirect heater |
Operating vacuum | 5·10-2 Pa |
Ultimate vacuum | 5·10-3 Pa |
Pump time | 15 min |
Pump type | Turbomolecular and rotary vane |
Manipulator, axis number | 4 |
Coordinate table | 300×320 mm |
Х, Y, Z axis travel | 800, 250 mm |
X, Y, Z axis movement speed | 0.1 – 40 mm/sec |
Table plate diameter | 300 mm |
Table plate aperture | 80 mm |
Rotation speed | 0.1 – 60 rpm |
Manipulator loading capacity | 70 kg |
Cooling system | Closed, integrated |
Pneumatic system | Integrated |
Supplies | Three-phase, 380V, 50 (60) Hz |
Weight | 2300 kg |
Beam power | 12 kW |
Welding chamber size | 360×360×360 mm |
Accelerating voltage | 60 kV |
Beam current MAX | 100 mA |
Beam current stability | 0.1 mA |
Beam deflection angle | ±7° |
Cathode | filament, indirect heater |
Operating vacuum | 5·10-2 Pa |
Pump time | 20 sec |
Vent time | 3 sec |
Table plate diameter | 200 mm |
Table plate aperture | 50 mm |
Rotation speed | 0.1 – 200 rpm |
EB gun travel | 150 mm |
Cooling system | Closed, integrated |
Pneumatic system | Integrated |
Supplies | Three-phase, 380V, 50 (60) Hz |
Beam power | 15 kW |
Welding chamber size | 2500×2500×2500 mm |
Accelerating voltage | 60 kV |
Beam current MAX | 250 mA |
Beam current stability | 0.1 mA |
Beam deflection angle | ±7° |
Cathode | Indirect heated |
Operating vacuum | 5·10-2 Pa |
Ultimate vacuum | 5·10-3 Pa |
Pump time | 20 min |
Manipulator, axis number | 5 |
Х, Y, Z axis travel | 1500, 1200, 1400 mm |
X, Y, Z movement speed | 0.1 – 50 mm/sec |
EB gun tilt angle | ±90° |
Table plate diameter | 900 mm |
Rotation speed | 0.1 – 5 rpm |
Supplies | Three-phase, 380V, 50 (60) Hz |
Beam power | 30 kW |
Welding chamber size | 4000×3000×3000 mm |
Accelerating voltage | 60 kV |
Beam current MAX | 500 mA |
Beam current stability | 0.1 mA |
Beam deflection angle | ±7° |
Cathode | Indirect heated |
Operating vacuum | 5·10-2 Pa |
Ultimate vacuum | 5·10-3 Pa |
Pump time | 20 min |
Manipulator, axis number | 5 |
Х, Y, Z axis travel | 3000, 2000, 2000 mm |
X, Y, Z movement speed | 0.1 – 50 mm/sec |
EB gun tilt angle | ±90° |
Table plate diameter | 900 mm |
Rotation speed | 0.1 – 5 rpm |
Supplies | Three-phase, 380V, 50 (60) Hz |
Beam power | 30 kW |
Welding chamber size | 5000×3500×4900 mm |
Accelerating voltage | 60 kV |
Beam current MAX | 500 mA |
Beam current stability | 0.1 mA |
Beam deflection angle | ±7° |
Cathode | Indirect heated |
Operating vacuum | 5·10-2 Pa |
Ultimate vacuum | 5·10-3 Pa |
Pump time | 20 min |
Manipulator, axis number | 5 |
Х, Y, Z axis travel | 4000, 2500, 3000 mm |
X, Y, Z movement speed | 0.1 – 50 mm/sec |
EB gun tilt angle | ±90° |
Table plate diameter | 900 mm |
Rotation speed | 0.1 – 5 rpm |
Supplies | Three-phase, 380V, 50 (60) Hz |
TECHNICAL DATA | |
Electron beam deflection | MAX ±7° |
Operating pressure MAX | 10-1 Pa * |
Connecting flange | ISO160 |
Gun height MAX | 500 mm |
TYPE | ACCELERATING VOLTAGE kV | POWER kW | BEAM CURRENT mA | CATHODE TYPE |
---|---|---|---|---|
TETA 6F30 | 30 | 6 | 200 | FILAMENT |
TETA 6P40 | 40 | 6 | 150 | PLASMA |
TETA 15H30 | 30 | 15 | 500 | INDIRECT HEATER |
TETA 30H30 | 30 | 30 | 500 | INDIRECT HEATER |
TETA 6F60 | 60 | 6 | 100 | FILAMENT |
TETA 15F60 | 60 | 15 | 250 | FILAMENT |
TETA 30H60 | 60 | 30 | 500 | INDIRECT HEATER |
TETA 60H60 | 60 | 60 | 1000 | INDIRECT HEATER |
TECHNICAL DATA | |
Electron beam deflection | MAX ±7° |
Operating pressure MAX | 10-1 Pa |
Connecting flange | ISO160 |
Gun height MAX | 640 mm |
TYPE | ACCELERATING VOLTAGE kV | POWER kW | BEAM CURRENT mA | CATHODE TYPE |
---|---|---|---|---|
TETA 6F150 | 150 | 6 | 40 | FILAMENT |
TETA 15F150 | 150 | 15 | 100 | FILAMENT |
TETA 30F150 | 150 | 30 | 200 | FILAMENT |
TECHNICAL DATA | |
Electron beam deflection | MAX ±7° |
Operating pressure MAX | 10-1 Pa |
Connecting flange | ISO160 |
Gun height MAX | 640 mm |
TYPE | ACCELERATING VOLTAGE kV | POWER kW | BEAM CURRENT mA | CATHODE TYPE |
---|---|---|---|---|
TETA 6FV30 | 30 | 6 | 200 | FILAMENT |
TETA 15HV30 | 30 | 15 | 500 | INDIRECT HEATER |
TETA 30HV30 | 30 | 30 | 500 | INDIRECT HEATER |
TETA 6FV60 | 60 | 6 | 100 | FILAMENT |
TETA 15FV60 | 60 | 15 | 250 | FILAMENT |
TETA 30HV60 | 60 | 30 | 500 | INDIRECT HEATER |
TETA 60HV60 | 60 | 60 | 1000 | INDIRECT HEATER |
TECHNICAL DATA | |
Electron beam deflection | MAX ±7° |
Operating pressure MAX | 10-1 Pa |
Connecting flange | ISO160 |
Gun height MAX | 640 mm |
TYPE | ACCELERATING VOLTAGE kV | POWER kW | BEAM CURRENT A | CATHODE TYPE |
---|---|---|---|---|
TETA 150H30 | 30 | 150 | 5 | FILAMENT |
TETA 300H30 | 30 | 300 | 10 | FILAMENT |
TETA 900H50 | 50 | 900 | 18 | FILAMENT |
CHARACTERISTICS | |
Accelerating voltage stabilization precision | 0.2 % |
Beam current stabilization precision | 0.1 mA |
Recovery time after electrical breakdown | 2 – 1000 ms |
External control | RS232, RS485, CAN |
TYPE | ACCELERATING VOLTAGE kV | POWER kW | BEAM CURRENT mA | CATHODE TYPE |
---|---|---|---|---|
TETA S6F30 | 30 | 6 | 200 | FILAMENT |
TETA S15H30 | 30 | 15 | 500 | INDIRECT HEATED |
TETA S30H30 | 30 | 30 | 500 | INDIRECT HEATED |
TETA S6F60 | 60 | 6 | 100 | FILAMENT |
TETA S15F60 | 60 | 15 | 250 | FILAMENT |
TETA S30H60 | 60 | 30 | 500 | INDIRECT HEATED |
TETA S60H60 | 60 | 60 | 1000 | INDIRECT HEATED |
TETA S15F150 | 150 | 15 | 100 | FILAMENT |
TETA S30F150 | 150 | 30 | 200 | FILAMENT |
